Introduction
Our Woods Skin Analyzer is a lamp made to examine and diagnose your skin type for proper facial treatment.This lamp has a 3x diopter magnifying lens and uses UV light to diagnose skin conditions.
It is a diagnostic tool used in dermatology to observe any subsequent fluoresce of the skin.
Under the Ultraviolet Lights, you can diagnose different skin conditions such as dry or oily areas, or excessive layers of dead skin, in which will show up under the violet light normally invisible to the naked eye.
Parameters
Voltage: | 110V, 220V, 230V, 240V |
Power: | 100w |
Rated input power: | 18W |
Frequency: | 50/60Hz |
Power Factor: | 0.31-0.33 |
Supply current: | 0.35A |
Maximum peak: | 365nm |
spectral range: | 320-400nm |
UV lamp: | philips 4x4w/08 |
Temperature: | 5-40 centigrade |
under the ultraviolet ray, different colors represent different skin conditions
Orange Points: Oily Skin
Light Yellow: Oily Acne Skin
Light Blue: Normal Healthy Skin
Brown Fluorescent: Pigmentation and Dark Spot
White Fluorescent: Thick Layer of Skin and Deak Cells
Purple and Dark Purple: Soft Skin, Dehydrated Skin, Skin Lacks Of Moisture
Wood Lamp Operations
1. Cleansing the skin
2. Cover client's eyes with cotton
3. Secure cover shade to wood lamp
4. Completely cover client's face with cover shade. the wood lamp should be parallel to client's face with distance of 15-20cm
5. Identify different skin characteristics by appearances of different colors under the ultraviolet ray
Cautions
In the operation, sometimes some small lightness dots appear, it is the deposit of cosmetic or atomy on the surface of skin, clean it and disappear.
Accessories
1x Main Wood Lamp
1 x Face drape
